Overview

The BCX5616QTA is a dual NPN transistor array designed for compact, high-gain switching and amplification tasks in consumer electronics, signal conditioning circuits, driver interfaces, and general-purpose amplification. Integrated into a single SOT-363 package, the device provides matched transistor performance, reduced PCB footprint, and enhanced thermal consistency. With collector current capability up to 100 mA, low saturation voltage, and high DC gain, the BCX5616QTA supports efficient, space-saving designs in cost-sensitive or miniaturized applications.

Core Parameters

Parameter	Specification
Transistor Type	Dual NPN
Package	SOT-363
Collector-Emitter Voltage (VCEO)	50 V
Collector-Base Voltage (VCBO)	60 V
Emitter-Base Voltage (VEBO)	5 V
Collector Current (IC max)	100 mA
Power Dissipation (PD)	200 mW
DC Current Gain (hFE)	100 to 630 (at IC = 2 mA)
Collector Saturation Voltage	90 mV typ (IC = 10 mA, IB = 0.5 mA)
Transition Frequency (fT)	100 MHz typ
Operating Temperature	–55°C to +150°C

Features

Dual NPN transistors in a single SOT-363 package for minimal board area
High DC gain (hFE up to 630) suitable for low-current amplification
Low VCE(sat) of 90 mV typical, reducing switching losses
Collector current up to 100 mA for moderate load driving
High 100 MHz transition frequency enabling higher-speed signal paths
Thermally matched dual device, improving consistency between channels
Ideal for switching, buffering, and small-signal amplification
Qualified over –55°C to +150°C, supporting demanding environments

Typical Application Scenarios

Application	Why BCX5616QTA Fits
Portable Electronics	SOT-363 minimizes footprint while supporting reliable switching
Signal Amplifiers	High hFE range delivers strong gain in low-current paths
LED Drivers & Indicators	Low saturation voltage improves efficiency
Sensor Signal Conditioning	Noise-sensitive circuits benefit from matched transistor characteristics
General Logic-Level Switching	Up to 100 mA collector current handles small actuators and digital loads
Consumer Electronics	Cost-effective, stable dual-transistor design suited for compact PCBs

Performance Comparison

Feature	BCX5616QTA	Standard NPN (Single)	Dual NPN (General)
Package	SOT-363 (dual)	SOT-23	Varies
DC Gain (hFE)	100–630	80–300	120–500
Collector Current	100 mA	100–200 mA	100 mA
VCE(sat)	90 mV typical	100–200 mV	100 mV typical
Matching	Yes	No	Partial

BCX5616QTA stands out with high gain, low saturation voltage, and tight dual-transistor matching inside a very small package.

Conclusion

The BCX5616QTA is a compact and efficient dual NPN transistor solution that enables high-gain amplification, low-loss switching, and space-saving PCB layouts. Its combination of high hFE, low VCE(sat), and 100 mA collector capability makes it ideal for portable devices, sensor interfaces, small actuators, and signal chain circuits requiring consistent transistor behavior. For engineers working on compact or cost-optimized designs, the BCX5616QTA delivers dependable and predictable performance.
