Overview
The MMA2712WCR2 is a high‑g digital MEMS accelerometer designed for robust motion and impact sensing applications. It is widely used in industrial machinery monitoring, automotive crash detection, and vibration/impact logging systems, where high acceleration range, digital interface, and reliable performance across temperature extremes are required. The device originates from NXP’s MMA27xxW family of DSI3 compatible inertial sensors.
Core Parameters
| Parameter | Specification |
|---|---|
| Sensor Type | Digital MEMS Accelerometer |
| Acceleration Range | ±125 g |
| Output Interface | PCM, SPI digital data |
| Supply Voltage | 4 V to 20 V |
| Operating Temperature | −40 °C to +105 °C |
| Package Type | 16‑pin QFN (6 × 6 mm) |
These parameters make the MMA2712WCR2 suitable for high‑impact and structural vibration sensing, especially where a wide supply voltage range and a digital interface are critical.
Features
- Digital acceleration output via PCM or SPI
- High‑g measurement up to ±125 g for impact/shock detection
- Selectable low‑pass filtering to reduce noise in dynamic signals
- Industrial temperature range (‑40 °C to +105 °C)
- Integrated configurability and diagnostic support from DSI3 family features
- Compact 16‑pin QFN package for space‑constrained designs
- Wide supply voltage supports embedded and automotive systems
Typical Application Scenarios
- Automotive impact and crash detection modules
- Industrial machine vibration and shock monitoring
- Structural health monitoring systems
- Robotics motion and impact sensing
- Safety system triggers in equipment and consumer electronics
For applications requiring an even higher acceleration range, the ADXL377BCPZ‑RL7 from Analog Devices serves as a complementary solution. With a ±200 g measurement range and robust analog output, it is ideal for extreme shock and impact monitoring, while MMA2712WCR2 remains suitable for precise ±125 g digital acceleration sensing. Designers can leverage both sensors in parallel or choose based on their system’s required g-range and interface preferences, providing flexibility for automotive, industrial, and high‑impact applications.
Performance Comparison
| Feature | MMA2712WCR2 | Typical Analog Accelerometer |
|---|---|---|
| Output Type | Digital (PCM/SPI) | Analog voltage |
| Acceleration Range | ±125 g | ±2 g to ±16 g |
| Noise Filtering | Selectable digital filter | Passive analog filtering |
| Voltage Range | 4 V–20 V | 3 V–5 V |
| Industrial Range | Yes | Limited |
Compared with typical analog accelerometers, MMA2712WCR2 provides a higher acceleration range, robust digital interface, and configurable filtering, enabling better performance in high‑impact and high‑noise environments.
Conclusion
The MMA2712WCR2 is a robust, high‑g digital MEMS accelerometer ideal for industrial and automotive applications requiring accurate impact and motion detection. Its digital output, selectable filtering, and wide supply voltage range simplify design integration and support reliable operation under harsh conditions.
Manufacturer Profile
NXP Semiconductors is a global leader in mixed‑signal and digital processing technologies. NXP’s MEMS inertial sensor families, including the MMA27xxW series, deliver reliable acceleration sensing solutions for industrial, automotive, and consumer markets backed by extensive documentation and long‑term support.
FAQ
- What acceleration range does MMA2712WCR2 support?
MMA2712WCR2 supports acceleration up to ±125 g, making it suitable for high‑impact and shock detection applications. - What output interfaces are supported?
The device provides digital output via PCM or SPI interfaces that interface directly with microcontrollers or DSP systems. - Can it be used in automotive applications?
Yes, like other MMA27xx series parts, it is suited for automotive and industrial environments with wide temperature range support. - How can I verify the quality of MMA2712WCR2?
7SEtronic follows a complete quality inspection SOP, including label verification, visual inspection, dimensional checks, X‑ray inspection, and electrical testing, ensuring authentic and reliable performance.
