Overview
The ST25R3915-AQFT is an automotive-grade HF/NFC reader IC designed to meet the rigorous requirements of modern NFC infrastructure, access systems, and in-vehicle electronics. It supports multiple industry protocols including ISO14443A/B, ISO15693, FeliCa, and ISO18092 (NFCIP-1). With an operating voltage range of 2.4 V to 5.5 V, a high RF output capability of up to 1 W, and bit rates reaching 848 kbit/s, the device delivers strong RF performance combined with reliable communication for demanding embedded applications. Its wide temperature range of –40°C to +125°C and AEC-Q100 Grade 1 qualification make it ideal for automotive environments.
Core Parameters
| Parameter | Specification |
|---|---|
| Supply Voltage | 2.4 V to 5.5 V |
| RF Output Power | Up to 1 W (differential drive) |
| Supported Standards | ISO14443A/B, ISO15693, FeliCa, ISO18092 (NFCIP-1) |
| Bit Rate | Up to 848 kbit/s |
| FIFO Size | 96 bytes |
| Wake-Up Detection | Capacitive, amplitude, phase |
| SPI Interface | 6 Mbit/s, 4-wire |
| Operating Temperature | –40°C to +125°C |
| Package | QFN32, 5×5 mm |
Features
- Automotive AEC-Q100 Grade 1 qualification
- Multi-standard NFC/HF reader: ISO14443A/B, ISO15693, FeliCa, NFCIP-1
- Differential antenna driver delivering up to 1 W RF power
- High bit-rate communication supporting 848 kbit/s
- 96-byte FIFO for efficient frame buffering
- Integrated low-power card detection via capacitive, amplitude or phase sensing
- Dual AM and PM demodulation channels for robust reception
- Supports 13.56 MHz or 27.12 MHz crystal operation
- Wide supply voltage suitable for vehicle systems (2.4–5.5 V)
- Ultra-low-power wake-up architecture for energy-sensitive systems
Typical Application Scenarios
| Application | Why ST25R3915-AQFT Is Suitable |
|---|---|
| Automotive NFC (door handle, center console, IVI) | AEC-Q100 Grade 1 qualification and high RF power ensure robust field performance |
| Secure Access Control | Multi-protocol support ensures compatibility with most commercial HF cards |
| Payment / Ticketing Terminals | High data rate and strong demodulation improve transaction reliability |
| Industrial NFC Systems | Wide temperature tolerance and strong HF output support demanding environments |
| Kiosk and Smart Infrastructure | Long-range HF capability with flexible low-power sensing modes |
Performance Comparison
| Parameter | ST25R3915-AQFT | Conventional HF Reader A | Conventional HF Reader B |
|---|---|---|---|
| RF Output Power | 1 W | 200–500 mW | ~600 mW |
| Protocol Support | ISO14443, 15693, FeliCa, NFCIP-1 | Limited | Broad |
| Wake-Up Methods | Capacitive, amplitude, phase | Basic amplitude | None |
| Operating Temperature | –40°C to +125°C | –20°C to +85°C | –40°C to +105°C |
| Automotive Grade | AEC-Q100 | No | Partial |
Conclusion
The ST25R3915-AQFT delivers a powerful combination of 1 W RF output, multi-standard NFC/HF compatibility, and automotive-grade robustness. Its advanced low-power detection features, wide operating voltage, and high-temperature endurance make it exceptionally well-suited for automotive NFC applications, smart access systems, industrial terminals, and embedded NFC-enabled devices. For designers requiring reliable performance, long range, and stringent automotive compliance, the ST25R3915-AQFT offers a complete HF reader solution.
Manufacturer Profile
STMicroelectronics (ST) is a global semiconductor leader known for producing reliable, high-performance mixed-signal ICs for automotive, industrial, and consumer markets. The ST25R series reflects ST’s expertise in NFC and HF reader technologies, combining strong RF capability, low-power operation, and wide protocol compatibility.
For more information and to review our available inventory, please contact our team for detailed pricing, current stock levels, and any additional technical support you may need.
